Wearable Health Monitor
Click to zoom
1 / 201Highlights
- Continuous PPG and SpO₂ biometric sensing
- Low-profile wrist-worn enclosure under 11 mm thick
- Qi wireless inductive charging
- 5-day battery life with always-on display mode
- Interchangeable silicone strap system
- IPX7 water-resistant construction
02Project Overview
A compact wrist-worn health monitor designed for continuous patient monitoring in both clinical and home settings. The ultra-slim form factor conceals the sensor array and battery within an 11 mm profile. Industrial design focused on comfort-first strap geometry, a scratch-resistant mineral glass lens, and a wireless charging surface that is flush with the underside of the device for one-hand dock placement.
03Key Components
Mineral glass display lensAluminium mid-frame with integrated antenna keep-outCustom silicone strap with quick-release lugOptical PPG / SpO₂ sensor windowInductive charging coil housingHaptic feedback motor mount
04Salient Features
- Sub-11 mm total thickness for all-day comfort.
- Continuous 72-hour biometric monitoring.
- Qi wireless charging — no exposed contacts.
- IPX7 rated for swimming and showering.
- Interchangeable strap system for clinical and consumer use.
- Scratch-resistant mineral glass lens.
05Scope of Work
01Wearable concept design and CMF
02Ergonomic wrist-geometry study
033D CAD and DFM for injection moulding
04Strap and clasp mechanism design
05Prototype build and fit evaluation
06IP rating compliance review
