Industrial Pressure Gauge
Click to zoom
1 / 501Highlights
- Robust pressure gauge enclosure design
- Stainless steel wetted parts
- IP65 ingress protection rating
- Panel-mount configuration
- Pressure range 0-1000 PSI
- ±0.5% accuracy class
02Project Overview
Robust pressure gauge enclosure with stainless steel wetted parts, IP65 rating, and panel-mount configuration for harsh industrial environments.
03Key Components
Stainless steel measurement housingPrecision Bourdon tubePanel-mount bracketProtective cover/windowIndustrial connectorDamping restrictor
04Salient Features
- Stainless steel construction for corrosion resistance.
- IP65 protection against dust and water.
- ±0.5% measurement accuracy class.
- 0-1000 PSI pressure range capability.
05Scope of Work
01Mechanical Design and CAD
02Material Selection
03Pressure Testing
04IP Rating Compliance
05Manufacturing Drawings
