Wireless Sensor Network Hub

Wireless Sensor Network Hub — image 1 of 6
Click to zoom
1 / 6
01Highlights
  • Multi-protocol wireless aggregation
  • Advanced mesh networking
  • Cloud connectivity
  • Automatic routing
  • 512 MB RAM
  • 256 device capacity
02Project Overview

Multi-protocol wireless hub aggregating sensor data from distributed IoT devices. Features advanced mesh networking with automatic routing and cloud connectivity for analytics.

03Key Components
Multi-radio Transceiver ModuleMesh Networking Processor512 MB RAM and StorageCloud Interface ControllerPower ManagementIndustrial Enclosure
04Salient Features
  • Support for BLE, Wi-Fi, and ZigBee simultaneously.
  • Advanced mesh networking with automatic routing.
  • Cloud connectivity for remote analytics.
  • Up to 256 connected devices.
  • 500m range in open space.
  • Low-power operation for extended deployment.
05Scope of Work
01System Architecture
02Wireless Protocol Integration
03Mesh Networking Implementation
04Cloud API Development
05Hardware Design
06Testing and Validation
