IR BLE AC Controller

IR BLE AC Controller - image 1 of 9
Click to zoom
1 / 9
01Highlights
  • IR and BLE based AC control platform
  • BLE mesh communication integration
  • Smart home embedded control architecture
  • Compact low-power embedded design
  • Wireless appliance automation support
  • Reliable multi-layer PCB integration
02Project Overview

IR BLE AC Controller is a smart embedded control platform designed for wireless air-conditioner automation using IR transmission and BLE mesh connectivity.

03Key Components
BLE communication moduleIR transmission circuitryEmbedded control processorPower management subsystemSignal routing layersWireless mesh networking interfaces
04Salient Features
  • Wireless BLE mesh appliance control
  • Reliable IR-based AC automation
  • Compact low-power embedded design
  • Scalable smart home integration
05Scope of Work
01Embedded Hardware Design
02Wireless Communication Integration
03PCB Layout Development
04Power Optimization
05Prototype Validation
