Pneumatic Test Jig
View Case
OBD Enclosure
Click to zoom
1 / 501Highlights
- Lightweight composite flow meter housing
- Integrated display window
- Snap-fit assembly design
- Inline installation compatibility
- Minimal pressure drop design
- Engineering plastic construction
02Project Overview
Lightweight composite flow meter housing with integrated display window, snap-fit assembly, and optimised for inline installation in fluid systems.
03Key Components
Engineering polymer housingTransparent viewing windowSnap-fit connector bodyMeasurement turbine assemblyFlow straightenerQuick-disconnect couplings
04Salient Features
- Lightweight engineering plastic construction.
- Integrated display window for reading.
- Snap-fit assembly for field serviceability.
- 1-100 L/min flow rate capability.
- Minimal pressure drop design.
05Scope of Work
01Enclosure Design and CAD
02Material Selection for Flow Compatibility
03Window Integration Design
04Flow Path Optimization
05Testing and Validation
