Gigabit Ethernet Switch Module
.png)
Click to zoom
1 / 401Highlights
- Three-phase power monitoring
- Comprehensive metering
- Harmonics analysis
- Fault detection
- Predictive maintenance
- 25 measurable parameters
02Project Overview
Three-phase power distribution monitoring device with comprehensive metering, harmonics analysis, and fault detection. Enables predictive maintenance of electrical infrastructure.
03Key Components
3-phase Measurement ICsHarmonics AnalyzerData Logging MemoryEthernet InterfacePower SupplyIndustrial Housing
04Salient Features
- 3-phase 480V monitoring capability.
- Class 0.5 measurement accuracy.
- 63rd order harmonics analysis.
- 25 measurable electrical parameters.
- Predictive fault detection algorithms.
- Cloud connectivity for remote monitoring.
05Scope of Work
013-phase Measurement Design
02Harmonics Analysis Implementation
03Fault Detection Algorithms
04Data Logging and Storage
05Ethernet Integration
06Testing and Validation
