02Project Overview
Automotive OBD2 PCB enabling multiple communication protocols with automotive-grade EMC hardening for vehicle diagnostics.
03Key Components
LQFP 64 microcontroller packageAutomotive OBD2 connectorESD protection circuitsCAN transceiverVoltage regulation for automotive supplyDiagnostic LED drivers
04Salient Features
- Multi-protocol support (UART, I2C, SPI).
- 4-layer automotive PCB stackup.
- High EMC/EMI immunity for in-vehicle operation.
- Optimized for diagnostics and data logging.
05Scope of Work
01Schematic Design
02PCB Layout Design
03EMC Compliance
04Testing and Validation
05Automotive Certification
